Features

* Suitable for use in conventional, interventional, diagnostic and therapeutic radiography and is valuable in vascular, cardiovascular, neurological and paediatrics examinations.

* Low exposure dose

* Stable performance

* High resolution imaging technology which resolves energy loss of traditional CCD detector and questions arising from geometric distortion

* Provides high quality distortion free images in real time

* Support 3D viewing

* Operating modes ranges from 30~100 images per seconds

Specifications

(1) Wireless flat panel detector:

Brand: Trixell

Size: 17" * 17" eqv. 43cm * 43cm

Matrix: 3008 * 3072

Spatial Resolution: 3.6 Lp/mm (Line pairs per mm)

Grayscale; 16 bit

Imaging time: < 5s

(2) High frequency x-ray generator

Brand: CPI

Rating; 150KV, 65KW, 1000KHz, 630mA

(3) X-ray tube

Brand: Toshiba

tube thermal capacity: 1250KHU

anode thermal capacity: 300KHU (Kiloheat unit)

dual focus rotating anode: 0.6mm ~ 1.2mm

(4) Mechanical specification

SID: 1000~ 1800mm (source image distance)

tube rotating range: 0~360 degrees
